NEUTRIK  NC3MXB  XLR Audio Connector, 3 Contacts, Plug, Cable Mount, Gold Plated Contacts, Metal Body, X Series

NEUTRIK NC3MXB
查看所有技術文件

圖片僅供舉例說明。 請參閱產品描述。

產品總覽

The NC3MXB is a 3-pole Male XLR Cable Connector with POM strain relief, latch locking device, black metal housing and silver over nickel plated brass contacts. It has polyamide insert, polyurethane boot, black chromium-plated zinc die-cast shell and zinc die-cast locking element. This X series connector can be assembled easily with only 4 parts and no screws, boot with rubber gland gives high protection against bending stresses.
  • Rugged zinc die-cast shell, long lasting and durable
  • Chuck type strain relief system for secure clamping of cables
  • Coloured rings and boots available for coding and marking
  • UL94HB Flammability rating
  • IP40 Protection rating
  • Complies with IEC 61076-2-103 standard
  • Solderability complies with IEC 68-2-20 standard
  • <=3mR Contact resistance
  • >10GR Insulation resistance
  • 16A Current rating per contact
  • <50V Voltage rating
  • -30 to +80°C Temperature range

產品訊息

No. of Contacts:
3Contacts
Gender:
Plug
Connector Mounting:
Cable Mount
Contact Plating:
Gold Plated Contacts
Connector Body Material:
Metal Body
Product Range:
X Series
SVHC:
No SVHC (17-Dec-2015)

按照共同屬性分組尋找類似產品

應用

  • Audio

法規與環境保護

原產地:
Switzerland

承擔產品生產最後程序之國家

符合 RoHS 規定:
關稅編號:
85366990
重量 (公斤):
.032
