Power Film Capacitors :
找到 4,363 個產品在 e絡盟台灣 找到大量 Power Film Capacitors 商品。我们备有各种 Power Film Capacitors 商品，包括来自世界顶级制造商的最新和最受欢迎的产品，这些制造商包括：Kemet, Vishay, TDK, Panasonic & Multicomp Pro。
所有篩選條件
展開所有
製造商
(1515)
(388)
(634)
(798)
(3)
(8)
(10)
(74)
(18)
Dielectric Type
(26)
(450)
(13)
(79)
(10)
(10)
(37)
(3525)
Capacitor Case / Package
(192)
(381)
(87)
(1)
(2342)
(905)
(2)
(142)
Capacitance
(1)
(7)
(1)
(4)
(1)
(1)
(8)
(1)
Capacitance Tolerance
(30)
(2)
(4)
(3)
(49)
(1737)
(1)
(5)
Typical Applications
(305)
(15)
(65)
(4)
(14)
(3)
(8)
(1)
Capacitor Mounting
(26)
(264)
(40)
(3)
(251)
(1)
(20)
(20)
Voltage(AC)
(8)
(12)
(1)
(1)
(21)
(12)
(20)
(2)
Voltage(DC)
(20)
(1)
(15)
(53)
(1)
(127)
(5)
(192)
Humidity Rating
(1320)
(113)
(356)
(317)
Capacitor Terminals
(32)
(1311)
(6)
(1)
(1945)
(389)
(85)
(65)
包裝
(4338)
(16)
(9)
(6)
| 比較 | 製造商產品編號 | 訂購編號 | 製造商 / 描述 | 庫存量 | 項目價格 | 價格 (含關稅，不含營業稅) | 數量 | Dielectric Type | Capacitor Case / Package | Capacitance | Capacitance Tolerance | Typical Applications | Capacitor Mounting | Voltage(AC) | Voltage(DC) | Humidity Rating | Capacitor Terminals | Lead Spacing | dv/dt Rating | Peak Current | RMS Current (Irms) | ESR | Product Diameter | Product Length | Product Width | Product Height | Ripple Current | Output (kvar) | Product Range | Operating Temperature Min | Operating Temperature Max | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Each | 1+NT$5.430 10+NT$4.080 50+NT$3.430 200+NT$2.860 400+NT$2.650 其他價格... | Metallized PET | Radial | 0.1µF | ± 5% | DC Link | Through Hole | - | 400V | - | PC Pin | 10mm | 30V/µs | - | - | - | - | 12mm | 5.5mm | 10mm | - | - | MP HMEF Series | -40°C | 105°C | - | ||||||
Each | 1+NT$23.530 50+NT$11.340 100+NT$10.280 250+NT$9.390 500+NT$8.490 其他價格... | Metallized PP | Radial Box - 2 Pin | 0.1µF | ± 5% | - | Through Hole | 250V | 630V | GRADE II (Test Condition A) | Radial Leaded | 15mm | - | - | - | - | - | 18mm | 7mm | 12.5mm | - | - | B32652 Series | -55°C | 110°C | AEC-Q200 | ||||||
Each | 1+NT$15.940 5+NT$11.730 10+NT$10.730 25+NT$9.510 50+NT$8.790 其他價格... | Metallized PP | Radial | 1µF | ± 5% | High Frequency | Through Hole | - | 400V | - | PC Pin | 15mm | 310V/µs | - | - | - | - | 18mm | 11.5mm | 17mm | - | - | MP HMPP Series | -40°C | 105°C | - | ||||||
Each | 1+NT$39.940 3+NT$27.970 5+NT$24.320 10+NT$17.250 20+NT$15.990 其他價格... | Metallized PET | Radial | 2.2µF | ± 5% | DC Link | Through Hole | - | 630V | - | PC Pin | 22.5mm | 12V/µs | - | - | - | - | 25mm | 15mm | 25mm | - | - | MP HMEF Series | -40°C | 105°C | - | ||||||
Each | 1+NT$399.640 10+NT$338.840 25+NT$317.810 50+NT$296.770 100+NT$263.250 其他價格... | Metallized PP | Radial Box - 2 Pin | 20µF | ± 5% | DC Link | Through Hole | - | 700V | - | Radial Leaded | 37.5mm | 17V/µs | 340A | 10.5A | 6000µohm | - | 42mm | 39mm | 24mm | - | - | MKP1848S Series | -40°C | 105°C | - | ||||||
Each | 10+NT$16.020 100+NT$11.030 500+NT$9.050 1000+NT$8.440 2000+NT$8.070 其他價格... | Metallized PP Stacked | Radial Box - 2 Pin | 2200pF | ± 5% | - | Through Hole | 400V | 630V | GRADE II (Test Condition A) | PC Pin | 10mm | - | - | - | - | - | 13mm | 4mm | 7mm | - | - | B32621 Series | -55°C | 105°C | - | ||||||
Each | 1+NT$8.110 10+NT$6.070 25+NT$5.120 50+NT$4.630 100+NT$4.290 其他價格... | Metallized PET | Radial | 1µF | ± 5% | DC Link | Through Hole | - | 250V | - | PC Pin | 15mm | 12V/µs | - | - | - | - | 18mm | 7mm | 14mm | - | - | MP HMEF Series | -40°C | 105°C | - | ||||||
Each | 1+NT$16.480 5+NT$12.240 10+NT$11.100 20+NT$9.800 40+NT$9.090 其他價格... | Metallized PP | Radial | 1µF | ± 5% | High Frequency | Through Hole | - | 630V | - | PC Pin | 22.5mm | 400V/µs | - | - | - | - | 25mm | 10.5mm | 17.5mm | - | - | MP HMPP Series | -40°C | 105°C | - | ||||||
Each | 1+NT$39.280 50+NT$22.390 | Metallized PP | Radial Box - 2 Pin | 0.01µF | ± 5% | High Frequency | Through Hole | 500V | 1kV | - | PC Pin | 10mm | 1.365kV/µs | - | - | - | - | 12.5mm | 5mm | 10.5mm | - | - | MKP1840M Series | -55°C | 100°C | - | ||||||
Each | 1+NT$186.660 2+NT$150.930 3+NT$128.650 5+NT$119.400 10+NT$110.150 其他價格... | Metallized PP | Can | 10µF | ± 5% | DC Link | Stud Mount - M8 | 450V | 1kV | - | Screw | 16mm | 200V/µs | 400A | - | 3200µohm | 42mm | - | - | 65mm | - | - | MP HDAT Series | -40°C | 85°C | - | ||||||
Each | 10+NT$5.370 100+NT$4.860 500+NT$4.460 1200+NT$4.040 | Double Metallized PP | Radial Box - 2 Pin | 0.027µF | ± 5% | High Frequency | Through Hole | 400V | 630V | GRADE II (Test Condition A) | Radial Leaded | 10mm | 4kV/µs | 108A | 3.6A | 0.024ohm | - | 13mm | 6mm | 12mm | - | - | R76 Series | -55°C | 110°C | AEC-Q200 | ||||||
Each | 5+NT$34.470 50+NT$17.400 250+NT$15.920 500+NT$13.410 1000+NT$12.630 其他價格... | Metallized PP | Radial Box - 2 Pin | 0.015µF | ± 5% | - | Through Hole | 500V | 1.6kV | GRADE II (Test Condition A) | PC Pin | 15mm | - | - | - | - | - | 18mm | 9mm | 17.5mm | - | - | B32652 Series | -55°C | 110°C | AEC-Q200 | ||||||
Each | 5+NT$39.610 50+NT$22.190 250+NT$20.710 500+NT$20.450 | Metallized PP | Axial Leaded | 0.047µF | ± 5% | High Current, Pulse | Through Hole | 100V | 160V | - | PC Pin | - | 240V/µs | - | - | - | 5.5mm | 11mm | - | - | - | - | MKP1839 Series | -55°C | 100°C | - | ||||||
Each | 10+NT$18.080 100+NT$12.760 500+NT$10.640 1000+NT$8.500 2000+NT$8.160 其他價格... | Metallized PP | Radial Box - 2 Pin | 0.01µF | ± 5% | - | Through Hole | 500V | 1.25kV | GRADE II (Test Condition A) | PC Pin | 15mm | - | - | - | - | - | 18mm | 6mm | 11mm | - | - | B32652 Series | -55°C | 110°C | AEC-Q200 | ||||||
Each | 1+NT$23.180 10+NT$15.340 50+NT$12.220 200+NT$11.680 | Metallized PP | Radial Box - 2 Pin | 0.01µF | ± 10% | - | Through Hole | 500V | 1.6kV | GRADE II (Test Condition A) | PC Pin | 22.5mm | - | - | - | - | - | 15mm | 26.5mm | 15mm | - | - | B32653 Series | -55°C | 110°C | AEC-Q200 | ||||||
Each | 1+NT$9,801.740 5+NT$8,122.760 10+NT$7,099.950 | Metallized PP | Can | 96.2µF | ± 5% | Three-Phase PFC | Stud Mount - M12 | 525V | - | - | Terminal Block | - | - | - | - | - | 84.4mm | - | - | 265mm | - | 25kvar @ 50Hz | ESTAspring PhMKP Series | -25°C | 65°C | - | ||||||
Each | 1+NT$23.130 5+NT$17.280 10+NT$14.550 25+NT$12.110 50+NT$11.230 其他價格... | Metallized PP | Radial | 1µF | ± 5% | High Frequency | Through Hole | - | 250V | - | PC Pin | 22.5mm | 130V/µs | - | - | - | - | 25mm | 6.5mm | 13.5mm | - | - | MP HMPP Series | -40°C | 105°C | - | ||||||
Each | 1+NT$63.110 10+NT$42.610 50+NT$34.510 100+NT$32.010 200+NT$29.870 其他價格... | Metallized PP | Radial Box - 2 Pin | 0.1µF | ± 5% | - | Through Hole | 500V | 1.25kV | GRADE II (Test Condition A) | PC Pin | 22.5mm | - | - | - | - | - | 26.5mm | 11mm | 20.5mm | - | - | B32653 Series | -55°C | 110°C | AEC-Q200 | ||||||
Each | 1+NT$98.930 5+NT$83.980 10+NT$69.020 25+NT$58.120 50+NT$57.560 其他價格... | Metallized PP | Radial Box - 2 Pin | 4.7µF | ± 5% | High Frequency | Through Hole | - | 600V | GRADE II (Test Condition B) | Radial Leaded | 27.5mm | - | - | - | - | - | 31.5mm | 12mm | 24.5mm | - | - | ECWFG Series | -40°C | 110°C | AEC-Q200 | ||||||
Each | 1+NT$1,441.900 5+NT$1,311.390 18+NT$1,180.880 54+NT$1,056.000 108+NT$1,034.880 | Metallized PP | Radial Box - 4 Pin | 210µF | ± 10% | DC Link | Through Hole | - | 500V | - | Radial Leaded | - | 15V/µs | 3.15kA | 47.7A | 1800µohm | - | 57.5mm | 45mm | 65mm | - | - | C4AQ-P Series | -55°C | 125°C | AEC-Q200 | ||||||
Each | 1+NT$82.350 10+NT$57.650 25+NT$53.850 50+NT$50.050 100+NT$43.710 其他價格... | Metallized PP | - | 1.5µF | - | DC Link | Through Hole | - | 900V | - | PC Pin | - | - | 105A | - | - | - | - | - | - | - | - | C4AQ-P Series | -55°C | - | AEC-Q200 | ||||||
Each | 1+NT$323.690 10+NT$268.080 | Metallized PP | Radial Box - 4 Pin | - | - | - | Through Hole | - | - | - | PC Pin | - | - | - | 27.5A | - | - | 57.5mm | 35mm | - | - | - | C4AQ-P Series | - | 125°C | AEC-Q200 | ||||||
Each | 1+NT$48.650 10+NT$29.160 50+NT$26.830 100+NT$24.500 500+NT$21.110 其他價格... | Metallized PP | Radial Box - 2 Pin | 0.039µF | ± 5% | High Frequency | Through Hole | 600V | 1.25kV | GRADE II (Test Condition A) | Radial Leaded | 15mm | 3.3kV/µs | 129A | 4.72A | 0.0204ohm | - | 18mm | 10mm | 16mm | - | - | R75H Series | -55°C | 125°C | AEC-Q200 | ||||||
Each | 1+NT$7.220 10+NT$5.390 50+NT$4.550 100+NT$3.280 200+NT$3.040 其他價格... | Metallized PP | Radial | 0.1µF | ± 5% | High Frequency | Through Hole | - | 630V | - | PC Pin | 15mm | 900V/µs | - | - | - | - | 18mm | 5mm | 10.5mm | - | - | MP HMPP Series | -40°C | 105°C | - | ||||||
Each | 1+NT$430.930 10+NT$357.120 50+NT$312.150 100+NT$231.380 200+NT$215.960 其他價格... | Metallized PP | Axial Leaded | 0.47µF | 5% | Snubber | Through Hole | 250V | 630V | - | PC Pin | - | 980V/µs | - | - | - | 21mm | 44mm | - | - | - | - | MKP1845 Series | -55°C | 100°C | - | ||||||
