Test Accessory, Matrix Card, Keithley 3700 & 3700A Series Mainframes


Image is for illustrative purposes only. Please refer to product description.

Manufacturer Part No:
Order Code:
Technical Datasheet:
3732   Datasheet
See all Technical Docs

Product Information

Want to see similar products? Simply select your required attributes below and hit the button ×

Matrix Card

Keithley 3700 & 3700A Series Mainframes


Find similar products Choose and modify the attributes above to find similar products.

Technical Documents (3)

Product Overview

The 3732 is an ultra-high density reed relay Matrix Card comprised of four banks, with 4 rows by 28 columns of reed relays. This provides 448 single-pole cross-points for maximum connection versatility in high channel count applications. For even greater flexibility, bank configuration relays are mounted on the card. It offers an automated method of connecting banks to enable two additional matrix configurations - single 4 x 112 and dual 4 x 56. This feature allows the matrix size to be easily adapted to existing or future applications. For differential measurements, a two-pole mode can be selected that enables automatic pairing of cross-points to create a dual 4 x 28 configuration. For larger matrix sizes, analogue backplane relays are provided that enable rows to connect to the series 3700A mainframe backplane. The card uses optimized reed relays that offer both low contact potential and low current offset to minimize the switching errors that often accompany this relay technology.
  • Analogue backplane connection relays provide easy card-to-card column expansion
  • Ideal for high channel count I-V testing with Series 2600A System SourceMeter® instruments
  • Long life dry reed relays (>10⁹ operations)


Industrial, Signal Processing, Test & Measurement

1 In stock Need more?

1 SG stock available for 1-2 business days delivery

Due to market conditions delivery times are for general guidance only and may be subject to change at short notice


Pricing is unavailable. Please contact customer services.

Price for:
Multiple: 1 Minimum: 1
  • 1+
Quantity Price (Incl GST) Your Price (Incl GST)
1+ NT$326,795.70
