160451-2
Quick Disconnect Terminal, FASTON 250, Female Quick Disconnect, 6.35mm x 0.81mm, 0.25" x 0.032"
需要更多？
| 數量 | 價格 |
|---|---|
| 10+ | NT$19.480 |
| 100+ | NT$16.560 |
| 500+ | NT$14.770 |
| 1000+ | NT$14.070 |
| 2500+ | NT$13.190 |
| 5000+ | NT$12.930 |
產品訊息
產品總覽
The FASTON 250 series FASTIN-FASTON Connector offers the advantage of the FASTON receptacles technology in multiple applications. In wiring harnesses, they are mainly used as multi-position and coupling connectors. Up to 8 position connectors can be mated in one operation with a maximum of 20 leads terminated. The receptacle in this version comply fully with the FASTON receptacles product technology. The only difference is the addition of a locking lance, which helps ensure firm retention of contacts when snapped into housings. Any application of this technology leads to essential time savings in final assembly.
- Used for single and multiple connections
- Receptacles available for 6.3, 4.8 and 2.8mm size
- Receptacles mate with 0.5 and 0.8 thick tabs
應用
Industrial
技術規格
FASTON 250
6.35mm x 0.81mm
18AWG
-
Uninsulated
No SVHC (04-Feb-2026)
Female Quick Disconnect
0.25" x 0.032"
14AWG
2.1mm²
Phosphor Bronze
法規與環境保護
承擔產品生產最後程序之國家原產地：Italy
承擔產品生產最後程序之國家
RoHS
RoHS
產品合規憑證
