T821116A1S100CEU
Pin Header, Wire-to-Board, 2.54 mm, 2 Rows, 16 Contacts, Through Hole Straight, T821 Series
6,576 有存貨
6,264 即日起您可預購補貨
1580 件可于 1-2 個工作日後配送(新加坡 件庫存)
4996 件可于 3-4 個工作日後配送(英國 件庫存)
| 數量 | 價格 |
|---|---|
| 10+ | NT$9.310 |
| 100+ | NT$9.130 |
| 500+ | NT$8.940 |
| 1000+ | NT$8.760 |
| 2500+ | NT$8.570 |
| 5000+ | NT$8.380 |
價格Each
最少: 10
多項: 10
NT$93.10
品項附註
僅針對此訂單新增至訂單確認、發票和出貨備註。
此數量將會新增至訂單確認、發票、出貨備註、網頁確認電子郵件和產品標籤。
產品訊息
製造商產品編號T821116A1S100CEU
訂購代碼2215308
Product RangeT821 Series
技術資料表
Connector SystemsWire-to-Board
Pitch Spacing2.54mm
No. of Rows2Rows
No. of Contacts16Contacts
Product RangeT821 Series
Connector ShroudShrouded
Contact MaterialBrass
Connector TypePCB Header
SVHCNo SVHC (21-Jan-2025)
產品總覽
T821116A1S100CEU is a 16-way straight box header with 2.5mm pitch and without latch.
- Phosphor bronze contact, glass-reinforced thermoplastic insulator
- Black colour housing
- Gold flash plating
- Straight THT termination
- 3A current rating
- 20mohm max contact resistance
- 1000Mohm min insulation resistance
- 1000V AC/minute withstand voltage
- Operating temperature range from -40°C to +105°C
技術規格
Connector Systems
Wire-to-Board
No. of Rows
2Rows
Product Range
T821 Series
Contact Material
Brass
SVHC
No SVHC (21-Jan-2025)
Pitch Spacing
2.54mm
No. of Contacts
16Contacts
Connector Shroud
Shrouded
Connector Type
PCB Header
T821116A1S100CEU 的替代選擇
找到 5 個產品
法規與環境保護
原產地：
承擔產品生產最後程序之國家原產地：China
承擔產品生產最後程序之國家
承擔產品生產最後程序之國家原產地：China
承擔產品生產最後程序之國家
關稅編號：85366930
US ECCN:EAR99
EU ECCN:NLR
符合 RoHS 規定：是
RoHS
符合 RoHS 鄰苯二甲酸酯類規定:是
RoHS
SVHC:No SVHC (21-Jan-2025)
下載產品合規憑證
產品合規憑證
重量 (公斤)：.002132
