35H-210-000-OR-900
Battery Disconnector Switch, Manual, Removable, Orange, Lever, 1 Poles, 250 A, 80 VDC, Flange
27 有存貨
需要更多？
27 件可于 3-4 個工作日後配送(英國 件庫存)
| 數量 | 價格 |
|---|---|
| 1+ | NT$2,968.990 |
| 5+ | NT$2,931.770 |
| 10+ | NT$2,894.540 |
價格Each
最少: 1
多項: 1
NT$2,968.99
品項附註
僅針對此訂單新增至訂單確認、發票和出貨備註。
產品訊息
製造商產品編號35H-210-000-OR-900
訂購代碼4378358
Product Range35H Series
技術資料表
Disconnect Switch TypeManual
Operating Voltage80VDC
Contact Current Rating250A
No. of Poles1Poles
Switch MountingFlange Mount
Operating Handle TypeLever
Termination Thread SizeM8
Switch KeyingRemovable
IP RatingIP67, IP6K9K
Product Range35H Series
SVHCLead (25-Jun-2025)
產品總覽
35H-210-000-OR-900 is a 250A battery disconnect switch.
- 80VDC operating voltage
- 250A switch main contact current rating
- Orange operating handle colour
- M8 termination thread size
- Lever operating handle type
- Screw hole diameter is 7mm
- Centerline between flange screw holes is 38mm
- Operating temperature range from -40 to 85°C
技術規格
Disconnect Switch Type
Manual
Contact Current Rating
250A
Switch Mounting
Flange Mount
Termination Thread Size
M8
IP Rating
IP67, IP6K9K
SVHC
Lead (25-Jun-2025)
Operating Voltage
80VDC
No. of Poles
1Poles
Operating Handle Type
Lever
Switch Keying
Removable
Product Range
35H Series
技術文件 (1)
法規與環境保護
原產地：
承擔產品生產最後程序之國家原產地：Slovak Republic
承擔產品生產最後程序之國家
承擔產品生產最後程序之國家原產地：Slovak Republic
承擔產品生產最後程序之國家
關稅編號：85365080
US ECCN:EAR99
EU ECCN:NLR
符合 RoHS 規定：不適用
符合 RoHS 鄰苯二甲酸酯類規定:不適用
SVHC:Lead (25-Jun-2025)
下載產品合規憑證
產品合規憑證
重量 (公斤)：.16
