Heavy Duty Connector, Insert, HA Series, Cable Mount, Receptacle, 16 Contacts, 2 Rows, Socket
圖片僅供舉例說明。 請參閱產品描述。
可供訂購
製造商標準交貨時間：14 週
有貨時通知我
| 數量 | 價格 |
|---|---|
| 1+ | NT$817.600 |
| 10+ | NT$753.530 |
| 25+ | NT$695.140 |
| 100+ | NT$654.170 |
| 250+ | NT$629.280 |
| 500+ | NT$616.700 |
價格Each
最少: 1
多項: 1
NT$817.60
品項附註
僅針對此訂單新增至訂單確認、發票和出貨備註。
產品訊息
製造商WEIDMULLER
製造商產品編號1650780000
訂購代碼1361604
Product RangeHA Series
其他名稱HDC HA 16 FS
技術資料表
Product RangeHA Series
Connector MountingCable Mount
GenderReceptacle(檢視相關連接器)
No. of Contacts16Contacts
No. of Rows2Rows
Contact GenderSocket
Contact Termination TypeScrew
Connector Shell Size5
Contact MaterialCopper
Contact PlatingSilver Plated Contacts
SVHCLead (23-Jan-2024)
產品總覽
The 1650780000 is a 16-position heavy-duty Female Insert with screw connection. The HDC series insert made of PC glass-fiber reinforced (UL-listed and railway-certified). It is suitable for use with HA series rectangular power connectors.
- 2.5mm² Conductor cross-section
- ≤2mΩ Volume resistance
- 10¹⁰Ω Insulation resistance
- ≥500 Plugging cycles (silver)
- 16A Rated current (DIN EN 61984)
- 4kV Rated impulse voltage (DIN EN 61984)
- 250V Rated voltage (DIN EN 61984)
- UL94V-0 Flammability rating
- -40 to 125°C Limit temperature range
應用
Power Management
技術規格
Product Range
HA Series
Gender
Receptacle
No. of Rows
2Rows
Contact Termination Type
Screw
Contact Material
Copper
SVHC
Lead (23-Jan-2024)
Connector Mounting
Cable Mount
No. of Contacts
16Contacts
Contact Gender
Socket
Connector Shell Size
5
Contact Plating
Silver Plated Contacts
法規與環境保護
原產地：
承擔產品生產最後程序之國家原產地：China
承擔產品生產最後程序之國家
承擔產品生產最後程序之國家原產地：China
承擔產品生產最後程序之國家
關稅編號：85366990
US ECCN:EAR99
EU ECCN:NLR
符合 RoHS 規定：是
RoHS
符合 RoHS 鄰苯二甲酸酯類規定:是
RoHS
SVHC:Lead (23-Jan-2024)
下載產品合規憑證
產品合規憑證
重量 (公斤)：.070307
